AGENT RADIO



FS-5000


fs1

FS-5000M modular radio transceiver was used by German Special Forces and agents(Stay Behind and Gladio Governmental Organisations).
The frequency coverage is from 50KHz to 29999MHz on receive( 1kc steps) and 2,0MHz to 29,999MHz (in 1kHz steps) on transmit at an output power of about 30 Watts HF. It was designed in the end of the 1980’s by the German AEG-Telefunken company for use by different NATO partners.
The system was designed to send short code burst messages (0,8 seconds for 52 characters) which can directly produced and edited with the DSU control unit.




fs2




fs4




fs5




fs3






kk78




kk75




kk76



kk77




kk79




kk66

Caption: SRR-4 Surveillance receiver.
The receiver has been developed by US Office of Technical Service (OTS) in 1961.
The radio covers frequency ranges from 50-200 MHz, and can demodulate FM, AM and CW signals.
Application: Exploration for hidden spy microphones, and interception of radio communications in the VHF band.
